Asphalt Drum Mix Plant
Stationary Asphalt Drum Mix Plant
Our Asphalt Drum Mix Plants are engineered for efficiency, reliability, and long-lasting performance, with production capacities ranging from 30 TPH to 150 TPH. Available in stationary and mobile configurations, these plants are designed to deliver consistent and high-quality output even under challenging site conditions.
Equipped with cold feed bins, high-efficiency drum mixers, fully automatic burners, and advanced control cabins, the plant ensures seamless operation with minimal manual effort. Additional components such as drag conveyors with discharge hoppers, asphalt tanks, fuel tanks, and wet scrubbers further enhance productivity and ease of use. For specific project requirements, optional bag filters and storage silos can be integrated to improve efficiency and flexibility.
Features
- Pre-wired and factory-tested for fast and hassle-free installation.
- Available in both portable (mobile) and stationary configurations.
- Designed for easy operation with minimal maintenance requirements.
- Standardized parts ensure quick replacements and reduced downtime.
- Offers high fuel efficiency while delivering superior asphalt quality.
- Equipped with a multi-cyclone dust collector for reduced environmental impact.
- Engineered to meet long-term performance standards with a proven, time-tested design.
Model
| MODEL | CAPACITY |
|---|---|
| TTDM-35 | 30 TO 35 TPH |
| TTDM-45 | 40 TO 60 TPH |
| TTDM-50 | 60 TO 90 TPH |
| TTDM-60 | 90 TO 120 TPH |
| TTDM-65 | 120 TO 150 TPH |
Technical Specifications
| PLANT MODEL | TTDM-35 (30–35 TPH) |
TTDM-45 (40–60 TPH) |
TTDM-50 (60–90 TPH) |
TTDM-60 (90–120 TPH) |
TTDM-65 (120–150 TPH) |
|
|---|---|---|---|---|---|---|
| No. of Bins | 3 | 4 | 4 | 4 | 4 | |
| Storage Capacity | 30 TONS | 41 TONS | 48 TONS | 51 TONS | 51 TONS | |
| Auxiliary Drive Motor | 2 HP × 3 Nos | 2 HP × 4 Nos | 2 HP × 4 Nos | 2 HP × 4 Nos | 2 HP × 4 Nos | |
| Auxiliary Conv. Belt | 2500 × 500 mm | 2500 × 500 mm | 2750 × 500 mm | 3000 × 500 mm | 3000 × 500 mm | |
| Auxiliary Conv. Gear Box | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | |
| Gathering Drive Motor | 5 HP | 5 HP | 5 HP | 5 HP | 5 HP | |
| Gathering Gear Box | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | |
| Gathering Conv. Belt | 19500 × 500 mm | 21500 × 600 mm | 23500 × 600 mm | 24500 × 600 mm | 24500 × 600 mm | |
| Bin Vibrator | OPTIONAL | 0.5 HP | 0.5 HP | 0.5 HP | 0.5 HP | |
| SLINGER CONVEYOR | ||||||
| Gathering Gear Box | 5 HP | 5 HP | 5 HP | 5 HP | 5 HP | |
| Gathering Conv. Belt | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | |
| Bin Vibrator | 12500 × 500 mm | 14400 × 600 mm | 14400 × 600 mm | 14400 × 600 mm | 14400 × 600 mm | |
| DRYING & MIXING UNIT | ||||||
| Drive Motor | 15 HP | 20 HP | 25 HP | 40 HP | 50 HP | |
| Drive Gear Box | HEAVY DUTY WORM GEAR BOX | |||||
| Exhaust Drive Motor | 15 HP | 20 HP | 25 HP | 40 HP | 50 HP | |
| LOAD OUT CONVEYOR | ||||||
| Conveyor Drive Motor | 5 HP | 5 HP | 5 HP | 5 HP | 5,7 HP | |
| Conveyor Drive Gear Box | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | SMSR / DIRECT | |
| Conveyor Belt | 16000 × 500 mm (SHR) | 17900 × 600 mm (SHR) | 17900 × 600 mm (SHR) | 17900 × 600 mm (SHR) | 17900 × 600 mm (SHR) | |
| BITUMEN TANK | ||||||
| Capacity | 10 Tons | 20 Tons | 20 Tons | 25 Tons | 30 Tons | |
| Bitumen Drive Motor | 3 HP | 5 HP | 5 HP | 5 HP | 5 HP | |
| Bitumen Jacketed Pump | 2" × 2" | 2" × 2" | 2" × 2" | 2" × 2" | 2" × 2" | |
| Suggested DG Set | 82 KVA | 92 KVA | 125 KVA | 160 KVA | 160 KVA | |
| Note: Due to "TTI" policy of continuous improvement / development, the technical data mentioned in the table is not binding and subject to change without notice. | ||||||
