Concrete Batching Plant
Our Concrete Batching Plant is a modern, high-performance solution designed to deliver superior quality concrete with precision and consistency. By combining cement, sand, aggregates, water, and admixtures in controlled proportions, the plant ensures uniform and reliable concrete batches for every project.
Built for accuracy, efficiency, and long-term reliability, it is an essential choice for constructing roads, bridges, industrial facilities, high-rise buildings, and major infrastructure projects. With its automated controls, the plant minimizes manual effort, reduces material wastage, and maximizes productivity.
Available in different capacities and configurations, our Concrete Batching Plants are designed to adapt to diverse project requirements, offering unmatched durability and flexibility.
Features
- Digital load cell-based weighing system ensures precise material proportions and consistent concrete quality.
- Mobile variants offer easy transport, quick installation, and minimal foundation requirements.
- Available in output capacities ranging from 20 m³/hr to 120 m³/hr for all project sizes.
- Fully automated PLC control system enables smooth operation and real-time monitoring.
- Energy-efficient motors and planetary gearboxes minimize power consumption.
- Rugged design and high-quality components reduce maintenance needs and enhance durability.
- Advanced material feeding system with in-line bins, screw conveyors, and skip buckets ensures smooth flow.
- 4.0-meter concrete discharge height allows direct loading into transit mixers
- Admixture dosing system provides accurate control over concrete properties.
- Controlled batching process reduces material wastage and supports eco-friendly operations.
Technical Specifications
| PLANT MODEL | TI – 20 | TI – 30 | TI – 45 | TST – 60 | TST – 75 | TST – 90 | TST – 120 |
|---|---|---|---|---|---|---|---|
| Output Capacity | 20 M³ / Hr. | 30 M³ / Hr. | 45 M³ / Hr. | 60 M³ / Hr. | 75 M³ / Hr. | 90 M³ / Hr. | 120 M³ / Hr. |
| Mixer Unit | Turbo pan type mixer / twin shaft mixer | ||||||
| Main Mixer Reduction Gear Box | Imported planetary reduction gear box | ||||||
| Main Driver / Electrical Motor | 20 HP | 30 HP | 40 HP | 50 HP | 60 HP | 50 HP × 2 Nos | 75 HP × 2 Nos |
| Material Storage Unit | In Line Four Bin Feeder | ||||||
| Material Storage Capacity | 20 M³ | 30 M³ | 40 M³ | 60 M³ | 60 M³ | 90 M³ | 100 M³ |
| Material Weighing System | Digital load cell based weighing of material | ||||||
| Batch Feeding System | Through inclined belt conveyor / Inclined skip bucket | ||||||
| Cement Feeding System | Through Screw Conveyor | ||||||
| Water Weighing System | Digital load cell based weighing of water in separate tank | ||||||
| Ad Mixture Dozing System | Digital load cell based auto admixture dosing system | ||||||
| Control Panel | Fully automatic PLC based control panel | ||||||
| Control Cabin | Provided | ||||||
| Concrete Discharge Height From G.I. | 4.0 meter from the ground level | ||||||
| Total Connected Power (HP) | 52 HP | 74 HP | 87 HP | 120 HP | 145 HP | 200 HP | 275 HP |
| Suggested DG Set | 62 KVA | 82 KVA | 125 KVA | 160 KVA | 200 KVA | 300 KVA | 400 KVA |
